Reliatronic Rubber Mat Linear Feeder

Reliatronic Rubber Mat Linear Feeder


Dongguan Chuangyu Electronic Co., Ltd. is a branch of Keepro Industry Group, founded in 2009 and specialized in developing and producing various high quality automatic feeders, like vibratory bowl feeders, centrifugal feeders, line feeders, step feeders, and robotic screw fastening machines, like handheld screw fatening machine, platform XYZ automatic screw robot and customized automatic screw fastening system upon our customers' demands. The main applicable industriesare automotive, home appliances, electronic, automobile, electrical components, 3C etc.

Product detail

Reliatronic Rubber Mat Linear Feeder

Features

1. Using frequency converter controller, no need to adjust spring or chip distance;
2. Easy mounting and positioning, no need further adjustment;
3. Small amplitude, no vibration interruption between the linear and bowl feeder;
4. 2 models are applicable to various applications.

Specification
Model AJ-HL04 AJ-L140 AJ-L190
Rated voltage V 200
Rated Current A 0.5 0.8 1.0
Vibration Fre HZ 200~300 20~120 50~90
Track length max mm 300 400 550
Track width max mm 50 50 65
Weight KG
Spring angle Degree 15
Controller AJ-31S
